stable-diffusion.cpp/docs/llada_image.md

How to Use

LLaDA-Image is a 6B text-to-image and instruction-guided editing model. The denoiser is a Lumina2/Z-Image-style NextDiT conditioned by a LLaDA2-MoE diffusion-LLM text encoder, and it reuses the Flux.2 VAE. Two checkpoints are published: a 50-step base model and LLaDA-Image-Turbo, a 4-step distilled model.

Download weights

Four components are required: a transformer, a text encoder, a VAE, and a connectors file holding the QueryFormer, the text projection and, for editing, the SigVQ image encoder.

The two published checkpoints are not interchangeable. LLaDA-Image-Turbo and LLaDA-Image ship different transformers, text encoders, QueryFormers and text projections; only the VAE, the SigVQ encoder and the tokenizer are shared. Mixing the two produces degraded output rather than a clean error, so keep each checkpoint's files together.

Both need an external LLaDA2 tokenizer.json, which is not embedded in sd.cpp and is the same file for either checkpoint. Take tokenizer/tokenizer.json from either repository and pass it with --tokenizer. See JSON tokenizers for CLI and C API usage.

LLaDA-Image-Turbo (4 steps)

Converted transformer, text encoder and pre-merged connectors are at https://huggingface.co/fszontagh/LLaDA-Image-Turbo-GGUF:

• llada-image-turbo-f16.gguf
• llada-image-turbo-text_encoder-q8_0.gguf
• llada-image-turbo-connectors.safetensors for text to image, or llada-image-turbo-connectors-edit.safetensors, which also carries the SigVQ encoder that editing needs.

Other quantizations of the transformer and the text encoder are in the same repository.

The VAE comes from the original repository, https://huggingface.co/inclusionAI/LLaDA-Image-Turbo: vae/diffusion_pytorch_model.safetensors, referred to below as llada_vae.safetensors.

LLaDA-Image (50 steps)

Converted transformer, text encoder and pre-merged connectors are at https://huggingface.co/fszontagh/LLaDA-Image-GGUF:

• llada-image-f16.gguf
• llada-image-text_encoder-q8_0.gguf
• llada-image-connectors.safetensors for text to image, or llada-image-connectors-edit.safetensors, which also carries the SigVQ encoder that editing needs.

Other quantizations of the transformer and the text encoder are in the same repository.

The VAE comes from the original repository, https://huggingface.co/inclusionAI/LLaDA-Image, and is the same file as the Turbo one.

Converting the weights yourself

The transformer has to go in through --diffusion-model so that its tensor names keep the prefix the loader expects, while the text encoder goes in through -m:

./bin/sd-cli -M convert --diffusion-model transformer/diffusion_pytorch_model.safetensors.index.json \
  -o llada-image-f16.gguf --type f16
./bin/sd-cli -M convert -m text_encoder/model.safetensors.index.json \
  -o llada-image-text_encoder-q8_0.gguf --type q8_0

Building the connector file yourself

--embeddings-connectors takes one file, so the QueryFormer, the text projection and (for editing) the SigVQ encoder have to be combined into a single Safetensors file, each tensor name prefixed with its component name. Leaving sigvq out skips loading the 2.6 GB encoder:

from safetensors.torch import load_file, save_file

merged = {}
for prefix, path in [
    ("queryformer", "queryformer/diffusion_pytorch_model.safetensors"),
    ("text_projection", "text_projection/diffusion_pytorch_model.safetensors"),
    ("sigvq", "sigvq/diffusion_pytorch_model.safetensors"),
]:
    for name, tensor in load_file(path).items():
        merged[f"{prefix}.{name}"] = tensor
save_file(merged, "llada_connectors.safetensors")

Examples

Text to image

./bin/sd-cli \
  --diffusion-model /path/to/llada-image-turbo-f16.gguf \
  --llm /path/to/llada-image-turbo-text_encoder-q8_0.gguf \
  --tokenizer /path/to/tokenizer.json \
  --vae /path/to/llada_vae.safetensors \
  --embeddings-connectors /path/to/llada-image-turbo-connectors.safetensors \
  --prompt "a lovely cat holding a sign says 'llada.cpp'" \
  --width 1024 \
  --height 1024 \
  --steps 4 \
  --cfg-scale 1.0 \
  --seed 42 \
  --output output.png

Image editing

./bin/sd-cli \
  --diffusion-model /path/to/llada-image-turbo-f16.gguf \
  --llm /path/to/llada-image-turbo-text_encoder-q8_0.gguf \
  --tokenizer /path/to/tokenizer.json \
  --vae /path/to/llada_vae.safetensors \
  --embeddings-connectors /path/to/llada-image-turbo-connectors-edit.safetensors \
  --ref-image /path/to/input.png \
  --prompt "change the sign text to 'sd.cpp'" \
  --width 1024 \
  --height 1024 \
  --steps 4 \
  --cfg-scale 1.0 \
  --diffusion-fa \
  --output output.png

See edit.md for the shared reference-image options. LLaDA-Image uses the llada_image preset by default, resizing the reference image to the output width and height before VAE encoding. SigVQ uses bilinear resizing to half the output resolution and inputs normalized to [-1, 1]. CFG keeps the source latent in both branches and uses SigVQ features only in the positive branch. Editing requires connectors that include the SigVQ weights.

Notes

• Use 4 steps and --cfg-scale 1.0 for LLaDA-Image-Turbo; the guidance is distilled away, so a higher CFG degrades output and doubles the text encoder cost. The 50-step base model uses --steps 50 --cfg-scale 5.
• Width and height are rounded up to a multiple of 16. For editing the reference pipeline requires them to be divisible by 32.
• Edit the 50-step base model at 1024x1024. At 512x512 it returns the reference image almost unchanged instead of applying the instruction; LLaDA-Image-Turbo edits correctly at both.
• Editing runs the reference and the target in one sequence, so it needs roughly twice the tokens of text to image at the same size. On 12 GB, editing at 1024x1024 needs --diffusion-fa; without it the diffusion graph does not fit.
• The weights total about 16 GB, but segmented execution streams them, so a much smaller budget works. At 512x512, --max-vram 6 costs almost nothing over unconstrained execution, and --max-vram 3 still produces byte-identical output at roughly 2.5x the time.
• --scheduler defaults to llada_image, which reproduces the reference Kumaraswamy sigma grid. --extra-sample-args uniform=1 selects the uniform grid instead.
• Prompt templating is handled automatically; pass a plain description.
• VQ-conditioned generation (generation_mode="vq", where the text encoder decodes image tokens before diffusion) is not implemented.
